The MD/GEN shell thing. Discussing some more details with one of my friends who has many experiences in mold design in computer industry. Final steps to go!💪💪💪
#transparentshell #sega #megadrive #genesis #retrogamer
Just noticed that I uploaded the cut video yesterday. Here is the full version: http://youtu.be/qqkOnivxcPw
Before you asking what it is, please just read the title and description of the video.
The final test today with RGR Famicom PiPU adaptor cartridge. 🙂
#pipu #nintendo #famicom #retrogamer #retrogaming #RaspberryPi
Tiny Famicom-Cart PCBA with FX2LP built in. Now, you just need a micro USB cable to run PiPU from you SBC(RPi and others)
In the video, it is 2 sides PCB with CHR-ROM position reserved, I also designed a PCB with just FX2LP + PRG-ROM and 1 side only.
#nintendo #PiPU #famicom
Sorry to make you guys wait for so long. Working hard to test the PCB and make this batch of MiniSS-CM4 ready.
Sorry for the delay and would have them posted as soon as possible!
#minisscm4 #raspberrypi #cm4 #rpi4 #retropie #retrogamer #retroging
First build of the sample from factory.
Noticed that I still have to do some modifications. Plz just wait few more days. Some fine tune is necessary. I insist to make it better now this one.
#transparentshell #nintendo #superfamicom #sfc #snes #supernintendo
Porting the PiPU project to Radxa Zero today, and it works smoothly.
Radxa Zero is small and powerful to stay in a Famicom cartridge shell. And it is power efficiency also.
Thanks to @rasteri started this PiPU project. I modified some code these few days, it is a good fun.
Some more parts came in today.
No more yellow power switch ring this time. As I did some modification and it looks better now.
#transparentshell #nintendo #sfc #superfamicom #supernintendo #snes #retrogamer
The very first injection test. Have to modify a bit but looks good.
#transparentshell #sfc #superfamicom #snes #supenintendo #Nintendo #retrogamer
